IMS Industrial Sewing Machines

TONY H-305 Walking Foot Zig Zag

TONY H-305 Walking Foot Zig Zag

Applications

For sewing medium to heavy weight fabrics which are difficult to feed when sewn.For such materials and products as wet suits, shoes, boots, leather, tarpaulins, neoprene.Federal Stitch 304Wet Suit version available for sewing neoprene rubber

Features

Large bobbin and horizontal axis transverse rotary hookWide zig-zagUpper feed mechanism helps avoid slippage when sewingReverse stitchingMaximum stitches per minute - 2000*Can use up to V138 / size 20 threadOptional: H-305-3 model available allows changing between single step, 2 step and 3 step stitch types; additional parts required (not included).
*Depending on the application

Specifications

Number of Needles 1 (Single)
Feeding Mechanism Walking Foot
Workspace Standard Workspace
Standard or Full Function Standard Functions
Speed, Max (S.P.M.) 2000
Clearence Under Presser Foot 25/64" (10mm)
Stitch Length 5 s.p.i. (5mm)
Work Space 10" (255mm)
Needle 135 x 17
Bobbin Metal

Bed Size 7" 18 7/8" (178m x 480mm)
Needle Bar Stroke 1-11/32" (34mm)
Hook Rotary
Zig-Zag Stitch Width 3/8" (9.5mm)

For more information on this or any of our product range please call us on :

1300 831 336  /  02 9569 0077

or fill in the product enquiry form below and we will respond ASAP.
